Universal CAN-BUS Adapter interface "CANTEC-F2" with CAN-BUS reading and various analog outputs

€109.00
Tax included
CANTEC-F2
1 Items

Specific References

The CANTEC-F2 it's an universal CAN-BUS adapter interface, designed to read and transform vehicle's CAN-BUS commands or signals into analogic outputs (Power - ground), or read and transform analogic outputs into CAN-BUS commands or signals.

Product Options
Configuración de parámetros via PC    * Required
Configuración de parámetros via PC :
Qty :

The CANTEC-F2 it's an universal CAN-BUS adapter interface, designed to read and transform vehicle's CAN-BUS commands or signals into analogic outputs (Power - ground), or read and transform analogic outputs into CAN-BUS commands or signals.

The CANTEC-F2 allows the perfect integration of aftermarket products and accesories into the vehicle's CAN-BUS, like alarms, immobilizers, PDC systems (Park Distance Control), GSM & GPS modules, multimedia devices or other aftermarket systems.

Compatible with most popular vehicles of the market. Due to the flexibility programming options, the CANTEC-F2 module is adapted to a wide range of applications, and can respond to the individual needs of each user. Programmable on the vehicle, or through the optional programming tool ref. TECPROG.


The CANTEC-F2 it's the MOST COMPACT AND SMALL universal CAN-BUS adapter interface of the WORLD!



Operation example: A typical CAN-BUS command of a vehicle as "Door opening", the module reads the signal when a door is opened at the vehicle, and by one of its many wires will get a positive signal (power).

Main features:

  • It's the world's smallest universal CAN-BUS adapter interface.
  • Compatible with most popular vehicles of the market.
  • Automatic vehicle recognition function.
  • 2 Programmable outputs with polarity change (+12V/ground) 200mA
  • 5 Programmable ground outputs 50mA
  • 3 Programmable +12V 50mA outputs
  • 3 Programmable ground 1.5mA inputs
  • 1 programmable input 6-4V 1.5mA
  • 24 Output functions available

Technical specifications:

  • Power 9-15V
  • Consumption 9W(stand-by 4mA)
  • Temperature -40°C a +85°C
  • Measures (only module) 30x30x7mm
  • Weight (Module with wires) 45g



Programmable output functions available:



Package Contents

1 x Universal CAN-BUS adapter interface "CANTEC-F2"
